Cable drum steel core, Type: 25N-4
Article no.: 081106 25N-4
Article code:
- IP Index of Protection: IP 44
- impact-resistant and splash-proof: Category 2 (K2) to BGI
Product details
Technical Data
| IP Index of Protection | IP 44 | |
| impact-resistant and splash-proof | Category 2 (K2) to BGI | |
| AC supply voltage | 230 V | |
| Rated power unrolled | 3500 (16 A) W | |
| Cable class | H07RN-F | |
| Cable structure | 3G2.5 | |
| Material cable | Rubber/neoprene | |
| Drum material | Sheet metal | |
| Cable colour | black | |
| Cable length | 25 m | |
| Number of sockets | 4 | |
| Number of sockets 230 V | 4 | |
| Diagnostic system present | yes | |
| Length | 22 mm | |
| Width | 30.5 mm | |
| Height | 39 mm | |
| Power supply | Mains-powered | |
| Type of product | Cable drum | |
| Number of sockets type F | 4 | |
| Rated current | 16 A |
Identification & Classification
| Article number | 081106 25N-4 | |
| EAN / GTIN | 4007123687633 | |
| Manufacturer/responsible person | Hugo Brennenstuhl GmbH & Co. KG, Seestraße 1-3, 72074 TÜBINGEN, Germany, www.brennenstuhl.de |
Description
Version:
The cable drums meet the specifications set out in DGUV I 203‑006 (formerly BGI 608).
Sturdy cable drum with drum body made of sheet metal, double insulated front and back.
Sturdy cable drum with drum body made of sheet metal, double insulated front and back.
