Bi-hexagon socket, 3/4 inch, Width across flats: 7/8in
Article no.: 644600 7/8
Article code:
- Square drive: 3/4
Product details
Technical Data
| Width across flats | 7/8 in | |
| Square drive | 3/4 in | |
| ⌀ drive output end | 33 mm | |
| Length | 51 mm | |
| Drive profile | Bi-hex socket | |
| Material | Chrome alloy steel | |
| Surface | chromium-plated over nickel | |
| Type of product | Socket insert |
Identification & Classification
| Article number | 644600 7/8 | |
| EAN / GTIN | 4018754009312 | |
| Manufacturer number | 05410044 | |
| Manufacturer/responsible person | STAHLWILLE Eduard Wille GmbH & Co. KG, Lindenallee 27, 42349 WUPPERTAL, Germany, www.stahlwille.de |
Description
Version:
Forged from high quality steel, internally bevelled for easy fitting to bolt heads. Close tolerance jaw widths. Internal square to DIN 3120-D 20 with hole and release button.
Standard:
DIN 3120-D 20
Material:
Chrome alloy steel, non-flaking, chrome-plated over nickel.
