Indexable insert for milling X.LT...ER-D41, for high feed rate milling cutter, KCMP30
Article no.: 221922 09
Article code:
New product
Product details
Technical Data
| ISO code indexable insert | XDLT090408-ER-D41 | |
| Indexable insert size | 09 | |
| Type | ST1400 | |
| Corner radius | 0.8 mm | |
| Type | KCMP30 | |
| Tool material | Carbide | |
| Programming radius at ap max | 2.01 mm | |
| Feed fz per tooth | 0.2 mm - 2.5 mm | |
| Number of changes/inserts | 4 | |
| Type of product | Indexable insert for milling |
Identification & Classification
| Article number | 221922 09 | |
| Manufacturer/responsible person | Kennametal Deutschland GmbH, Raiffeisenstraße 10, 61191 ROSBACH VOR DER HÖHE, Germany, www.kennametal.com |
Application Table
P
340
P
260
P
210
P
180
P
155
Description
Version:
Particularly thick indexable inserts with ground wiper chamfer.
Note:
Standard application values for ae = 0.3×D.
