Torque screwdriver with 1/4 inch bit holder, with scale, automatic triggering, maximum torque: 30cNm
Article no.: 659985 30
Article code:
- Direction of tightening: Right-hand tightening
- Torque measuring accuracy: ±6
- Bit socket: D 6.3; F 6.3
- Test certificate: Manufacturer’s test certificate
Product details
Technical Data
| Direction of tightening | Right-hand tightening | |
| Torque measuring accuracy | ±6 % | |
| Bit socket | D 6.3; F 6.3 | |
| Test certificate | Manufacturer’s test certificate | |
| Overall length L | 196 mm | |
| Torque range | 2 cNm - 30 cNm | |
| Torque range | 0,02 Nm - 0,3 Nm | |
| Scale graduation, 1 graduation = | 0,2 cNm | |
| Display | analogue | |
| Release signalling | haptic | |
| Trigger principle | mechanical slip clutch | |
| Connection format | Bit holder 1/4 inch | |
| Measurement technology | mechanical | |
| Torque fixed setting | no | |
| Data can be recorded | no | |
| Setting the trigger value | with adjustment scale | |
| Feedback | triggering | |
| Reversible reading | Nm; cNm | |
| Measurement process | Torque | |
| Adjustable trigger value | adjustable | |
| Standard | DIN EN ISO 6789 | |
| Type of product | Torque screwdriver |
Identification & Classification
| Article number | 659985 30 | |
| EAN / GTIN | 4000896260027 | |
| Manufacturer number | 6004CT-3 | |
| Manufacturer/responsible person | HAZET-WERK Hermann Zerver GmbH & Co. KG, Güldenwerther Bahnhofsstraße 25-29, 42857 REMSCHEID, Deutschland, www.hazet.com |
Description
Version:
- Very easy to read thanks to large, clear numeric display.
- Short 36° release distance with clearly audible signal.
- Bit holder (1/4 inch – D 6.3 / F 6.3) with quick release fastener – fast bit changes with one hand.
- “Ratchet function” with free-running mechanism, reversible and can be locked, enables fast working due to smooth re-gripping action when tightening/loosening screw connections, even in confined spaces
- Release mechanism made of high-alloy tool steel – wear resistant.
- Overload clutch (“Slipper”) ensures the set value is not exceeded.
- Lock symbols clearly indicate the locking status.
- 2-component system made of high-quality, glass fibre-reinforced plastic and softer TPE grip zones.
- Actuating direction “left” enables loosening without torque limitation.
- “Made in Germany”
Function:
Screwdriver releases audibly and perceptibly when the set value is reached and is immediately ready for operation again.
Standard:
Tested to DIN EN ISO 6789.
Accuracy:
±6 %.
