Milling Toolholder - MEAS40-S32-13-3T

Milling Toolholder MEAS40-S32-13-3T

RE (GTC - Corner radius, Pos. A): 0.8 mm
WT (GTC - Weight of item): 0.993 kg
CNSC (GTC - Coolant entry style code): 1
Number of inserts: 3
CXSC (GTC - Coolant exit style code): 3
ZEFF (GTC - Face effective cutting edge count): 3
ZEFP (GTC - Peripheral effective cutting edge count): 3
S (GTC - Insert thickness, Pos. A): 5.1 mm
AN (GTC - Clearance angle major, Pos. A): 7 Degree
RMPX (GTC - Ramping angle maximum): 8.5 Degree
IC (GTC - Inscribed circle diameter, Pos. A): 9.9 mm
W1 (GTC - Insert width, Pos. A): 9.9 mm
Cutting length (APMX): 12
APMX (GTC - Depth of cut maximum): 12 mm
L (GTC - Cutting edge length, Pos. A): 16.216 mm
Shank diameter (DCON): 32
DCON (GTC - Connection diameter machine side): 32 mm
LU (GTC - Usable length): 32 mm
BD (GTC - Body diameter): 38.5 mm
DC (GTC - Cutting diameter): 40 mm
OHX (GTC - Protruding length): 55 mm
EPSR (GTC - Cutting edge angle major, Pos. A): 57 Degree
Cutting angle: 90
KAPR (GTC - Tool cutting edge angle): 90 Degree
LS (GTC - Shank length): 100 mm
Total length (OAL): 150
LF (GTC - Functional length): 150 mm
OAL (GTC - Overall length): 150 mm
CZCMS (GTC - Connection size code machine side): 320
Insert size: 1305
RPMX (GTC - Rotational speed maximum): 42000 1/min
Recess (LDN): 50,0
Shank type: Cylindrical
TCDCON (GTC - ISO-tolerance class connection bore diameter machine side): h6
Diameter (DC): ø40
HAND (GTC - Cutting direction): R
BMC (GTC - Body material code): S
Internal coolant: Yes
