Turning Toolholder - CRDNN2525M-12A
Article no.: THA00570
Article code:
Please note the delivery time and limited advice:
We order this item for you directly from the manufacturer, as it is not part of our main range and is therefore not in stock with us.
InfoProduct details
Technical Data
| Type of product | Clamp toolholder |
Identification & Classification
| Article number | THA00570 | |
| EAN / GTIN | 4960664003907 | |
| Manufacturer number | THA00570 | |
| L-Number | L22460 184 | |
| Manufacturer/responsible person | KYOCERA UNIMERCO Tooling GmbH, Hammfelddamm 6, 41460 NEUSS, Germany, www.kyocera-unimerco.de |
Description
Description:
Turning Toolholder CRDNN2525M-12A
Feature:
LAMS (GTC - Inclination angle): -8.5 DegreeAN (GTC - Clearance angle major, Pos. A): 0 DegreeCNSC (GTC - Coolant entry style code): 0 CXSC (GTC - Coolant exit style code): 0 S (GTC - Insert thickness, Pos. A): 3.18 mmInsert size: 12 WF (GTC - Functional width): 12.5 mmIC (GTC - Inscribed circle diameter, Pos. A): 12.7 mmShank height (H): 25 Shank width (B): 25 B (GTC - Shank width): 25 mmH (GTC - Shank height): 25 mmHF (GTC - Functional height): 25 mmHead length (LH): 29 KAPR (GTC - Tool cutting edge angle): 45 DegreeTotal length (LF/OAL): 150 LF (GTC - Functional length): 150 mmOAL (GTC - Overall length): 150 mmCZCMS (GTC - Connection size code machine side): 2525 Type: N HAND (GTC - Cutting direction): N Internal coolant: No MIID (GTC - Master insert identification): RNMN120300
