Softcut® shoulder mill with bore, for indexable inserts AO..
Article no.: 215411 80/10
Article code:
New product
- Setting angle κ: 90
- Milling application: Ramping; Circular milling; Ramping; Plunging
- Spacing of the cutters: unequal spacing
- Through-coolant: yes
- Machining strategy: MTC; MTC
Product details
Technical Data
| Series | Softcut® | |
| Cutting edge ⌀ DC | 80 mm | |
| Number of cutting edges Z | 10 | |
| Shank type | with bore | |
| Setting angle κ | 90 degrees | |
| Milling application | Ramping; Circular milling; Ramping; Plunging | |
| Spacing of the cutters | unequal spacing | |
| Through-coolant | yes | |
| Machining strategy | MTC; MTC | |
| Tool exchange | PowerCard | |
| Overall length Ltot | 50 mm | |
| Mounting bore ⌀ | 27 mm | |
| suitable indexable insert | AO.T1104 | |
| Set of insert screws | 219799 10 (8IP; 1.5 Nm) | |
| Type of product | Indexable end mill |
Identification & Classification
| Article number | 215411 80/10 | |
| EAN / GTIN | 4069515038966 | |
| Manufacturer number | 215411 80/10 | |
| Manufacturer/responsible person | Hoffmann Supply Chain GmbH & Co. KG, Poststraße 15, 90471 Nürnberg, Germany, www.hoffmann-group.com |
Description
Version:
High precision square shoulder mill with irregular pitch for very smooth cutting, very high precision and cutting power. With special geometry for reduced cutting forces for MTC applications under unstable conditions or for spindles with low drive power.
Application:
For shoulder milling in large depths, also slotting. General use in all steel materials as well as stainless and acid-resistant steels.
