Impact wrench 18 V, cordless impact wrench
Article no.: 074010 M18ONEF1DS
Article code:
New product
- Packaging: Modular case (HD=Heavy Duty)
- suitable battery - supplier / battery type / voltage: Milwaukee type B 18 V
- App link: OneKey
Product details
Technical Data
| Packaging | Modular case (HD=Heavy Duty) | |
| suitable battery - supplier / battery type / voltage | Milwaukee type B 18 V | |
| App link | OneKey | |
| Manufacturer's designation | M18ONEFHI-WF1DS-121C | |
| Number of rechargeable batteries contained | 1 | |
| Power supply | Battery-powered | |
| Type of rechargeable battery | Lithium-ion | |
| Battery capacity | 12 Ah | |
| Battery voltage | 18 V | |
| maximum torque 1st step | 1,180 Nm | |
| maximum torque 2nd step | 1,254 Nm | |
| maximum torque 3rd step | 1,966 Nm | |
| maximum torque 4th setting | 2,576 Nm | |
| maximum screw ⌀ (8.8 - 12.9) | M42 | |
| Number of impacts 1st stage | 0 min-1 - 750 min-1 | |
| Number of impacts 2nd stage | 0 min-1 - 930 min-1 | |
| Number of impacts 3rd stage | 0 min-1 - 1,200 min-1 | |
| Number of impacts 4th setting | 0 min-1 - 1,440 min-1 | |
| Tool arbor drive profile | External square drive | |
| Tool arbor size | 1 in | |
| Weight | 11.1 kg | |
| typical application | Heavy Duty | |
| Type of product | Impact wrench |
Identification & Classification
| Article number | 074010 M18ONEF1DS | |
| EAN / GTIN | 4058546564179 | |
| Manufacturer/responsible person | Techtronic Industries Central Europe GmbH, Walder Straße 53, 40724 HILDEN, Germany, www.milwaukeetool.de |
Description
Version:
Robust and powerful FUEL™ cordless impact wrench with brushless POWERSTATE™ EC motor, for long motor service life and high energy efficiency. Sturdy metal gearbox casing and ergonomic central handle with soft-grip coating. Stage of charge display, LED illumination of the working area. Reversible, with electronic speed control. REDLINK PLUS™ electronics − for unique power management:
DRIVE CONTROL™ permits quick switching between the 4 available settings with different speeds and torques.
- With system communication between the drive machine and battery.
- With overload protection for longer working life of the battery, motor, and gearbox.
DRIVE CONTROL™ permits quick switching between the 4 available settings with different speeds and torques.
With 18 FUEL™ ONEKEY™ 1 inch cordless impact wrench with snap ring, provides up to 2576 Nm of tightening torque and replaces wired, petrol and pneumatic devices. DRIVE CONTROL enables quick switching between the 4 available settings with different speeds and torques.
Advantage:
DRIVE CONTROL™ .
Supplied with:
Includes 1× M18 Forge™ 12 Ah, charger, HD box.
